Product details

Rotating Resistance

18X7 19X7

Use

Excellent flexibility due to the flattened surface

Very strong rotation - resistance



Rotating Resistance

DIA(mm) 18X7 19X7
App w.t(Kg/m) Min B.S(kgf) App w.t(Kg/m) Min B.S(kn)
AISI 302, 304 AISI 316 AISI 302, 304 AISI 316
6.00 14.4 19.60 18.03 15.1 20.87 18.52
8.00 25.6 35.08 31.95 26.9 37.04 32.93
9.00 32.4 44.30 40.47 34.0 46.84 41.65
10.00 40.0 54.78 49.98 42.0 57.92 51.45
11.00 48.4 66.44 60.47 50.8 70.07 62.23
12.00 57.6 78.79 71.93 60.5 83.30 74.09
13.00 67.6 92.61 84.38 71.0 97.80 86.93
14.00 784.0 106.82 97.90 82.3 113.68 100.94
15.00 90.0 122.50 111.72 94.5 129.36 114.66
16.00 102.0 139.16 127.40 108.0 147.98 131.32
18.00 130.0 177.38 162.68 136.0 187.18 166.60
19.00 144.0 197.96 180.32 152.0 207.76 185.22
20.00 160.0 218.54 199.92 168.0 231.28 205.80
22.00 194.0 265.58 242.06 203.0 280.28 248.92
